MOVE S2
I0 SQ1 Measuring cell O32 YV2 Valve dropping fingers
I1 SQ3 Pusher lift system high O33 YV3 Valve air blast
I2 SQ4 Pusher lift system low O34 YV4 Valve pusher guide
I3 SQ5 Pusher in referencing position O35 YV5A Valve pusher lift system high
I4 SQ6 Dropping fingers down O36 YV5B Valve pusher lift system low
I5 SQ7 Dropping fingers up O48 KM1 Relay hydraulic pump
I6 SQ11 Main access cover safety O49 KM2 Relay chain loader motor M3
I8 SQ13 Reference dropping fingers O50 KA5 Relay dropping fingers high
I15 SP1 Air pressure switch O51 KA6 Relay dropping fingers low
I16 K1 Safety line relay O54 SON Motor Servo ON
I17 SP2 Oil pressure switch
I18 SQ10 Retraction safety switch
I19 SQ8 Indexing chain loader
I20 SQ9 Bar stocks on chain loader
I21 SQ15 Safety grid switch
I22 SQ16
Chain loader optical safety
switch
INT0 SQ14 Dropping fingers pulse input
I24 A1 Clamping device signal O56 R1 Alarm relay
I25 A2 Lathe in auto cycle O57 R2
Relay bar feeder in loading
cycle
I26 A3 Feed order O58 R3 Relay End of bar
I27 A4 Push order O59 R4 Relay automatic mode
I28 A.. Programmable interface input O60 R5 Relay auxiliary end of bar
I29 A.. Programmable interface input O61 R6 Option
I30 A.. Programmable interface input O62 R7 Option
I31 A.. Programmable interface input O63 R8 Option
