CHAPTER 4: OPERATION 43
MOVE S2
Screen "End of bar position":
Press the key corresponding to the icon
Depending on which sequence the bar feed is in when the parameter is
selected, the available functions and icons can change :
Available functions
By offset correction By teaching
-
- Icon Icon
- Icon ---
By offset correction:
Press the key corresponding to the icon .
The current end of bar position (Z) is displayed.
Enter with the direction keys the correction to insert, and press the
icon to add the value, or the icon to subtract it. The new value
is stored and displayed.
To exit the end of bar set mode, press the key attributed to the icon
.
By teaching:
Press the key attributed to the icon . The display shows
the current end of bar position.
Press the key and advance the pusher to the desired position
(see previous page).
To validate the new end of bar position, keep pressed until
the icon disappears.
To exit the set mode, press the keys or .
