CHAPTER 3: SETTING INTO OPERATION 25
MOVE S2
Before turning the power on, check that the voltage of the bar feeder corresponds to that
of the lathe. The voltage of the bar feeder is indicated on the identification plate.
The interface cable(s), between the bar feeder and the lathe is (are) provided by LNS.
Although an example of an interface diagram is provided, the diagram for the interface corresponding to
your device, essential when making the electrical connection, is located inside the electrical cabinet.
When making connections, ensure that the cables are long enough to allow the entire travel of the
retraction system (470 mm).
Should the interface instructions not be observed during the setting into operation, the
damaged elements as well as the resulting damages are not covered by warranty.
