32
Vista Pro 6 Server: Viewing Mode
CONFIGURING MOTION DETECTION AREA
To configure the camera’s motion detection area:
1. Click the Setup ( )button and then click the Motion tab. The Motion tab opens.
2. Click the Motion Detection Area button. The Motion configuration screen opens.
3. Under Select Camera, select the camera you wish to apply the setting to.
4. Under Motion Detection Area, select Full Area or Partial Area.
• If Partial Area is selected, you can select certain portions of the screen to detect motion
To select a certain portion of the screen, click the
Add button. Next, drag your cursor in the
preview screen of the area you wish to select. A box with a number appears in the selected
area. Repeat to add a new selection area.
Preview screen
Motion Detection
settings
Figure 8.1 Motion configuration window.
Select
Camera
Selected area for motion
detection.
Figure 8.2 Motion detection
area selection.
