MacDon R113 - Page 113

215585 105 Revision A

$
Figure 5.13: Repositioning Hitch Stand
14. Rotate stand (A) upward and into storage position.

%
$
Figure 5.14: Hitch Stand in Storage Position
15. Insert pin (A) and secure stand (B) in storage position.
CONNECTING THE TRACTOR TO THE ROTARY DISC PULL-TYPE
