MacDon R113 - Page 143

215585 135 Revision A

$
%
&
'
(
)
*
+
Figure 7.9: Lubrication Points
A - Slip Joint, Steering Link B - Guard, Clutch Driveline
C - U-Joint, Clutch Driveline D - Clutch
E - Bearing, Driveline (R113 PT, One Place) (R116 PT, Two Places) F - U-Joint, Driveline (R113 PT, One Place) (R116 PT, Two Places)
G - Guard (R113 PT, One Place) (R116 PT, Two Places) H - Guard (R113 PT, One Place) (R116 PT, Two Places)
LUBRICATING THE ROTARY DISC PULL-TYPE
