215585 170 Revision A
%
$
Figure 9.13: Transport Latch
1. If tightened, loosen bolts (B) on transport latch (A).
NOTE:
This step only needs to be completed the first time the
machine is converted from field to transport.
$
%
&
Figure 9.14: Control Box
2. Clear bystanders from the area and start tractor. Do NOT
operate the rotary disc pull-type.
3. Following the steps on field-to-transport decal (A), move
transport switch to lower position (C) and ensure that
light (B) is illuminated.
TRANSPORTING THE ROTARY DISC PULL-TYPE
