215585 174 Revision A
%
$
Figure 9.24: Transport Mode
13. Activate hazard lights (A) on the rotary disc pull-type.
Ensure all lights are working.
14. Ensure that slow moving vehicle sign (B) is visible from
behind the rotary disc pull-type.
$
%
&
Figure 9.25: Control Box
15. Once field-to-transport conversion (A) is complete, leave
the switch in upper position (C). Ensure that light (B) is
NOT illuminated.
TRANSPORTING THE ROTARY DISC PULL-TYPE
