MacDon R113 - Page 23

215585 15 Revision A

$
Figure 3.18: Hitch Pin
12. Tighten outer bolts (A) first to draw the plate against the
frame, and then tighten the inner bolts.
13. Torque bolts to 461 Nm (340 lbf·ft).
ASSEMBLING THE ROTARY DISC PULL-TYPE – WITH OR WITHOUT THE DEALER-INSTALLED TRANSPORT
