Maeda MC815C - Page 8

0-6
Item
Page
FLY JIB
5-1
1. NAME OF EACH SECTION OF FLY JIB 5-2
2. FLY JIB HYDRAULIC SYSTEM 5-3
2.1 SOLENOID OPERATED DIRECTIONAL CONTROL VALVE (JIB SWITCHING SOL) 5-3
2.2 HOSE REEL 5-4
2.3 DERRICKING CYLINDER (FOR FLY JIB) 5-5
2.4 TELESCOPING CYLINDER (FOR FLY JIB) 5-6
2.5 SELECTOR VALVE BLOCK (FLY JIB TELESCOPIC CYLINDER MOUNTED) 5-7
3. FLY JIB 5-8
3.1 FLY JIB (MAIN BOOM SIDE) 5-8
3.2 FLY JIB (FLY JIB SIDE) 1/2 5-9
3.3 FLY JIB (FLY JIB SIDE) 2/2 5-10
4. FLY JIB HARNESS 5-11
4.1 FLY JIB HARNESS 1/3 5-11
4.2 FLY JIB HARNESS 2/3 5-12
4.3 FLY JIB HARNESS 3/3 5-13
5. FLY JIB SAFETY DEVICE 5-14
5.1 PIN TYPE LOAD CELL (LOAD TRANSDUCER) 5-14
5.2 LENGTH METER REEL (FLY JIB MOUNTED) 5-15
5.3 ANGLE DETECTOR (FLY JIB MOUNTED) 5-16
5.4 LENGTH GAUGE REEL (MAIN BOOM MOUNTED (COMMON TO BOOM LIGHT SPECIFICATIONS) ) 5-18
6. FLY JIB ELECTRICAL CIRCUIT DIAGRAM 5-19
7. TROUBLESHOOTING 5-20
7.1 LIST OF ERROR CODES 5-20
7.2 WHEN THESE PHENOMENA HAPPEN 5-21
8. SPECIFICATIONS 5-22
8.1 SPECIFICATION TABLE 5-22
8.2 SPECIFICATION DIMENSIONAL DRAWING 5-22
8.3 RATED TOTAL LOAD CHART 5-23
8.4 WORKING RADIUS/LIFTING HEIGHT 5-24
SEARCHER HOOK
6-1
1. NAMES OF SEARCHER HOOK PARTS 6-2
2. SEARCHER HOOK ASSEMBLY 6-3
3. CHANGING SEARCHER HOOK ANGLE 6-4
4. CHANGING TO SEARCHER HOOK MODE 6-5
5. TROUBLESHOOTING 6-6
6. SPECIFICATIONS 6-7
6.1 SPECIFICATION TABLE 6-7
6.2 SPECIFICATION DIMENSIONAL DRAWING 6-7
6.3 RATED TOTAL LOAD CHART 6-8
6.4 WORKING RADIUS/LIFTING HEIGHT 6-9
