36
Mahr GmbH • Millimar C1202
Tolerance values for the lower value
and the upper value must be entered
relative to the nominal size.
If a greater number is entered for
the lower value than for the upper
value, the numbers will appear in
yellow. The entries cannot be saved.
– Use the ▼ key to select the digit and
the ▼ or ▲ keys to enter the relevant
value.
– Use the 4 key to conrm the value or
Ó to exit the submenu.
– Use
▼
to select Upper value or ▲ or
Ó to nish editing the tolerance and
to accept changes, or Ó to exit
the Tolerance Editor without saving
the changes.
