Spare parts required for maintenance
11.3 Spare parts for the carrier
25.11.2016
Maintenance manual 3 302 364 en 11 - 7
GMK 4100L-1
Assemblies and spare parts
Carrier
GROVE-
part number
Quantity, in single parts
For maintenance interval
Y 2 Y 3 Y 5 Y 6 Y 10
Engine
Oil filter with cover gasket
04163013 1
Original oil drain plug, complete 04161529 1
Transmission
Filter
03328342 1
Spring 03328343 1
Gasket 42 x 49 Al DIN 7603 03328344 1
Gasket 24 x 29 Cu DIN 7603 00117145 2
