Maintenance work on the carrier
7.14 Hydraulic system
13.02.2018
Maintenance manual 3 302 719 en 7 - 97
GMK6300L-1
Changing filters 3
and 4
Filter 3 is installed on the left side and filter 4 is on the right side.
• Remove the receptacle (1).
• Place the filter in a receptacle.
• Change the filter (2).
• If necessary, replace any defective
parts (repair set).
• Fill the receptacle with clean oil.
• Put the receptacle on and tighten it.
• Change the filter on the opposite side in
the same way.
O
Risk of damage to the environment from filter residues
Store used hydraulic oil filter inserts in suitable receptacles and have
them disposed of properly by qualified personnel.
