Manitowoc Grove GMK6300L-1 Maintenance Manual

Spare parts required for maintenance
11.2 Lighting
11 - 2 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
Installation point GROVE part
number
Designation Power (W)
CARRIER LIGHTING:
Front spotlights:
(integrated in the bumper)
– Daytime driving light 03328445 P21W 24 V 21
– Low-beam + full-beam headlights 03134828 H7 24 V 70
– Low-beam + full-beam headlights (USA) 03143584 H9 12 V 65
– Indicator light 03327578 PY21W 24 V 21
– Parking light (in the direction indicator light) 03140908 LED
– Yellow side marker light 03320937 LED
Front, side indicator lights:
(at the access ladder to the driver's cab)
– Indicator light 03327578 8GA 006841241 24 V / 21 W
Tail lights:
(at the rear of the chassis and on the removable outrigger box)
– Marker light 03137450 R5W 24 V 5
– Number plate light 03137450 R5W 24 V 5
– Rear light 03137450 R5W 24 V 5
– Brake light 03328445 P21W 24 V 21
– Indicator light 03137451 PY21W 24 V 21
– Fog tail light 03328445 P21W 24 V 21
– Reverse light 03328445 P21W 24 V 21
Licence plate lamp, external:
(at the rear of the chassis)
– LED licence plate light 04163112 LED
Yellow side marker lights:
(at the sides, along the chassis)
– Side marker light 03323568 LED
White rear marker lights:
(at the rear of the chassis)
– Left marker light 03327625 LED
– Right marker light 03327626 LED
Reversing lamp:
(at the rear of the chassis)
– Reversing lamp; complete 03143180 LED
