Spare parts required for maintenance
11.2 Lighting
13.02.2018
Maintenance manual 3 302 719 en 11 - 3
GMK6300L-1
Red triple light strip for USA:
(at the rear of the chassis)
– Triple light strip 7581100056 LED
White front marker lights:
(at the top on the driver's cab)
– Marker light 03138527 LED
Yellow additional lights for USA:
(at the top on the driver's cab)
– Yellow side marker light 03320937 LED
Outrigger beam spotlights:
(above the front and rear outrigger beams)
– LED spotlight; complete 03143786 M70 LED
or:
– Filament lamp 02316460 8GH 002090251 70
Yellow rotating beacons:
(on the driver's cab)
– Rotating beacon; complete 04156048
Inside lights:
(in the driver's cab)
– Filament lamp 00550434 K 24 V 10
Dashboard light:
(in the driver's cab; socket 12V)
– Filament lamp 04159964 Xenon 12V / 6W
s
Installation point GROVE part
number
Designation Power (W)
