TMS800E SERVICE MANUAL ELECTRIC SYSTEM
3
GROVE
Published 01-29-2014, Control # 496-00
Table 3-5
Amp Crimping Tool Table
Table 3-6
Deutsch Extraction Tool Table
Table 3-7
Deutsch Crimping Tool Table
Description Amp Part Number Grove Part Number
Tool Die Tool Die
14 to 12 gauge wire 69710-1 90145-1 9-999-100177 N/A
10 to 8 gauge wire 69710-1 90140-1 9-999-100177 9-999-100178
4 to 9 circuit
(in-line connectors
69710-1 90306-1 9-999-100177 N/A
15
(in-line connectors
90299-1 -- N/A --
Description Deutsch Part Number Grove Part Number
12 gauge wire 114010 9-999-100194
16 gauge wire 0411-204-1605 9-999-100195
8-10 gauge wire 114008 7-902-000012
4-6 gauge wire 114009 7-902-000009
Description Deutsch Part Number Grove Part Number
12, 14, 16, 18, 20 gauge wire HDT-48-00 9-999-100808
4, 6, 8, 10 gauge wire HDT04-08 9-999-100842
Reference Only
