7-21
TMS800E SERVICE MANUAL POWER TRAIN
Published 01-29-2014, Control # 496-00
Installation
1. Install SCR to the muffler mount weldment with the
mounting bands. Ensure there is a 3 mm (.13 in) gap
between the SCR and the muffler mount weldment floor.
2. Connect the adapter tube to the SCR with a V-Band
clamp and gasket.
3. Install the DPF and secure with the mounting bands.
4. Connect the elbow and decomposition tube to the DPF
and adapter tube with the appropriate gaskets and V-
Band clamps.
5. Connect the exhaust tube to the DPF with a V-Band
clamp and gasket.
6. Install the covers and guards.
Reference Only
