Manitowoc Grove TMS800E User Manual

1-3
TMS800E SERVICE MANUAL INTRODUCTION
1
GROVE
Published 01-29-2014, Control # 496-00
Rear
Type . . . . . . . . . . . . . . . . . Single reduction tandem
Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.38:1
Brakes
Type . . . . . . . . . . . . . . . . . . . . .Air operated S-Cam
Size . . . . . . . . . . . . . .(16.5 x 7.0 in) 419 x 178 mm
Wheel And Tires
Lugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Torque . . . . . . . . . . (450 - 500 lb-ft) 610 to 678 Nm
Tire Size
Front . . . . . . . . . . . . . . . . . . . . . . 445/65R22.5
Rear . . . . . . . . . . . . . . . . . . . . . . 315/80R22.5
For roading and lifting pressures, refer to the Tire
Inflation Decal.
Swing Gearbox
Reduction Ratio . . . . . . . . . . . . . . . . . . . . . . .33.6:1
Output Torque . . . . . . . . . . . . . . . . . . . 72,222 lb-in
Boom
Length . . . . . . . . . . (41 to 128 ft) 12.5 to 39 meters
Power. . . . . . . . . . . . . . . . . . .4 Section, Full Power
Elevation . . . . . . . . . . . . . . . . . . -3 to +78 degrees
Extensions
Fixed* . . . . . . . . . . . . . . . . . . (33 ft) 10 meters
Folding*. . . . . . . . (33 or 56 ft) 10 or 17 meters
Lattice Extension. . . . . . . . . . . . . . . . . . . . . (20
and 40 ft) 6.1 and 12.2 meters
*Extensions are offsettable at 0, 20, or 40 degrees
Swivel Assembly
Electrical. . . . . . . . . . . . . . . . . . . . . . . 19 Slip Rings
Hydraulic . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 ports
Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 ports
Hydraulic Pumps
NOTE: Pump output figures are theoretical.
Pump #1 (QSM Engine)
Type . . . . . . . . . . . . . . . . . . . . . . . . . . Piston/Piston
Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Output (at 2012 rpm)
Section 1 (piston) . . . .(57.1 gpm) 216.15 l/min
Section 2 (piston) . . . . .(40.8 gpm) 154.4 l/min
Pump #2 (QSM Engine)
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Gear
Sections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Output (at 2012 rpm)
Section 1. . . . . . . . . . . . .(20.1 gpm) 76.1 l/min
Pump #3 (QSM Engine)
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . Gear/Gear
Sections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Output (at 1750 rpm)
Section 1. . . . . . . . . . . . .(19.4 gpm) 73.4 l/min
Section 2. . . . . . . . . . . . .(19.4 gpm) 73.4 l/min
Pump #1 (ISX Engine)
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . Piston/Gear
Sections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Output (at 1900 rpm)
Section 1 (piston) . . . . .(96.3 gpm) 364.5 l/min
Section 2 (gear) . . . . . . .(18.9 gpm) 71.5 l/min
Pump #2 (ISX Engine)
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Gear
Sections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Output (at 1670 rpm)
Section 1. . . . . . . . . . . . .(18.7 gpm) 70.8 l/min
Pump #3 (ISX Engine)
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Gear
Sections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Output (at 1670 rpm)
Section 1. . . . . . . . . . . . .(16.7 gpm) 63.2 l/min
Hoists
Drum Dimensions
Diameter . . . . . . . . . . . . . . . . . .(15 in) 381 mm
Length (Standard). . . . . . . . . . .(18 in) 467 mm
Cable
Diameter . . . . . . . . . . . . . . . . . . (3/4 in) 19 mm
Length-Main . . . . . . . . . . . . . . . .(600 ft) 183 m
Length-Aux. . . . . . . . . . . . . . . . .(607 ft) 185 m
Max. Permissible Line Pull (6x36)
(16,800 lb) 7,620 kg
Max. Single Line Speed . . . . . (514 fpm) 157 m/min
Hoist Motor Displacement
Low 6.53 in
3
/rev (107 cm
3
/rev)
High 3.72 in
3
/rev (61 cm
3
/rev)
Reference Only
