washers between the radiator and the mounts to adjust
radiator height properly.
2. Position the fan guards on the shroud and secure with
bolts, washers, and lock washers.
3. Attach the left and right side baffles to the front cowl with
the attaching hardware.
4. Connect the hoses to the top and bottom of the radiator.
5. Ensure the drain cock is closed.
6. Connect the CAC tubes to the CAC.
7. Connect the coolant recovery hoses to the radiator.
8. Position the top center panel, with doors attached, on
the front and rear cowl and secure with the attaching
hardware.
9. Service the engine coolant system as necessary. Start
the engine, operate all systems and check for leaks.
10. Position the front cowl on the frame and secure with the
attaching hardware
11. Position the front grill panel on the front cowl and secure
with the attaching hardware.
WINTER FRONT GRILL COVER
1. When coming into winter operation season, install the
winterfront grill cover on the grill panel with ten 6-32
UNC SAE-2 hex nuts and ten No. 6 lock washers.
2. Clean cover with soap and water as needed during
winter season operation. Blow cover dry with
compressed air.
3. Remove and stow cover when not needed.
