4-26
Published 01-29-2014, Control # 496-00
BOOM TMS800E SERVICE MANUAL
FIGURE 4-5
6510-3
10
11
12
6510-8
8
1
2
Item Description
1 Stinger
2 Front Mount
3 Upper Hangar
4 Lower Support
5 Rear Hangar
6 Carrier
6510-7
8
3
4
5
6
7
9
6916-1
Item Description
7 Bumper Pad
8 Holding Plate
9Jib
10 Pin
11 Pin
12 Bracket
Reference Only
