Manitowoc Grove TMS800E - Page 181

4-39
TMS800E SERVICE MANUAL BOOM
4
GROVE
Published 01-29-2014, Control # 496-00
FIGURE 4-51
6622-1
6622-2
3
3
2
1
2
1
6568-4
Shown At 20 ° Offset
Offset
Link
To obtain maximum
degree offset, remove pin
and stow in lug.
Shown At 40 ° Offset
6568-3
6568-2
Pin
Pin
Offset
Link
FIGURE 4-52
Shown At 0° Offset
Mast Assembly
Pin Assembly
Reference Only
