5-13
TMS800E SERVICE MANUAL HOIST AND COUNTERWEIGHT
Published 01-29-2014, Control # 496-00
NOTE: It may be necessary to jog the counterweight with
the removal control panel to remove the weight of
the counterweight from the upper attach pins.
3. Using the counterweight removal control panel, raise the
counterweight cylinders to relieve weight on the upper
attach pins. Push in, turn, and remove the upper attach
pins from the superstructure frame lugs and the
counterweight
4. Stow the upper attach pins in the bushings on the side of
the superstructure.
5. Push in, turn, and remove the long pins from the bottom
of the counterweight.
6. Using the removal control panel, slowly lower the
counterweight onto the carrier stowage area.
7. Insert the long pins through the carrier lugs and
counterweight. Push in and turn to lock pin in the notch.
8. Remove the attach pins from the counterweight lugs and
cylinder ends. Raise the cylinders and stow the attach
pins in cylinder and insert retainer clip pins.
9. The carrier is now ready for highway travel with the
counterweight stowed.
Item Description
1 Counterweight Removal Cylinder
2Spacer
3Bolt
4 Washer
5 Cylinder Attach Pin Assembly
6 Capscrew
7 Counterweight Weldment
8Nut
9 Counterweight Weldment (18,000# Only)
10 Box Attach Pin
11 Counterweight Weldment Attach Pin
12 Hoist(s)
13 Turntable
14 Counterweight Removal Control Panel
15 Counterweight Weld- LH (Optional)
16 Counterweight Weld - RH (Optional)
Reference Only
