7-12
Published 01-29-2014, Control # 496-00
POWER TRAIN TMS800E SERVICE MANUAL
FIGURE 7-5
1
8
2
5
4
7
6
3
9
10
Item Description
1 Fuel Return From Fuel Cooler
2 Fuel Level Sending Units
3 Tank Vent
4 Fuel Tank
Item Description
5 Filler Cap
6 Mounting Straps
7 Fuel Tank Brackets
8 Fuel Supply To Engine
9 Fuel Return (ISX-Back Side)
10 Fuel Return (QSM)
Reference Only
