POWER TRAIN TMS800E SERVICE MANUAL

TORQUE

149 to 163 Nm

110 to 120 ft-lb)

TORQUE

149 to 163 Nm

(110 to 120 ft-lb)

TORQUE

149 to 163 Nm

(110 to 120 ft-lb)

TORQUE

149 to 163 Nm

(110 to 120 ft-lb)

TORQUE

136 Nm

(100 ft-lb)

TORQUE

149 to 163 Nm

(110 to 120 ft-lb)

Drive Line Installation

View A

Reference Only
