Manitowoc Grove TMS800E - Page 45

2-9
TMS800E SERVICE MANUAL HYDRAULIC SYSTEM
2
GROVE
Published 01-29-2014, Control # 496-00
9
5
4
2
8
6
3
1
7
FIGURE 2-3
6979
Item Description
1 Reservoir
2 Return Filter
3 Return Manifold Inlet
4 Sight Gauge (Oil Level Gauge)
Item Description
5 Access Cover
6 Filler Cap
7 Drain Plug (Not Shown)
8 Thermometer
Reference Only
