Manitowoc Grove TMS800E User Manual

2-23
TMS800E SERVICE MANUAL HYDRAULIC SYSTEM
2
GROVE
Published 01-29-2014, Control # 496-00
6551
SUPERSTRUCTURE
CARRIER
FIGURE 2-13
6550-5
1
5
4
2
3
7
9
10
6
8
Item Description
1 Turntable
2 Accessory Manifold with Swing Directional Valve
3 Pilot Operated Check Valve (Cab Tilt)
4
Counterweight Removal/Cab Tilt Directional
Control Valve
5 Hoist/Telescope/Lift Directional Control Valve\
6 Outrigger Selector Valve
Item Description
7 Motor Control Manifold
8 Charge Oil Cooler Control Manifold
9 Rear Outrigger Control Manifold
10 Front Outrigger Control Manifold
Reference Only
