HYDRAULIC SYSTEM TMS800E SERVICE MANUAL
2-40
Published 01-29-2014, Control # 496-00
9
FIGURE 2-25 continued
6546-2
1
11
6
3
2
5
10
4
7
8
Item Description
1 Gauge Port (GP7)
2
Port B (To Front and Rear Outrigger
Outrigger Control Manifolds
3Relief Valve
4 Pressure Beyond Port (PB)
5 Port A (To Stabilizer Cylinders)
6 Solenoid Valve (Retract)
Item Description
7 Inlet Port (P)
8 Tank Port (T)
9 Solenoid Valve (Extend)
10 Solenoid Valve (Pressure Beyond)
11 Directional Control Valve (Retract - Extend)
12 Check Valves (Cylinder Retract)
Reference Only
