HOW TO PROGRAM THE E4N COLUMN
This section provides instructions on how to program the E4N column and make use of the
column's full potential.
Use "one ch." programming for measuring tasks involving the use of one sensor only.
Use "two ch." programming for measuring tasks involving the use of two sensors to carry out
one measurement or when two measurements have to be carried out with the same column, each using
one sensor.
Use " all" programming for measuring tasks involving the use of up to four sensor to carry out
one measurement, or when threeor four measurements have to be carried out with the same column,
each using one sensor.
PROGRAMMING TYPES
The table below shows the types of measurement tasks that the E4N column can perform for
each of the programming types.
Decide the type of programming you wish to use, than use the ow charts
provided in Section 3.8 and 3.9 as a guide through the programming pro-
cedure for each variable.
two ch. all ch.one ch.
DIAMETER
DISTANCE
CONCENTRICITY
PERPERNDICULARITY
ROUNDNESS (TRI-LOBE)
CYLINDRICITY
PARALLELISM
T.I.R.
