57
4
4.4
PROGRAMMING EXAMPLES FOR THE E4N COLUMN
GAP MEASUREMENT WITH TWO SENSORS
EQUIPMENT REQUIRED:
A FOUR-CHANNEL E4N COLUMN
A MANUAL RING GAUGE TYPE MARPOSS M4
A MANUAL BORE GAUGE TYPE MARPOSS M1 STAR EBG
TWO SIGNAL SPLITTING CABLES
On the programming data sheet the parameters for which a value
must be programmed are shown in bold type.
The programming data sheet also shows the default values.
Variable data not shown are not part of this measurement example and can
be ignored.
DATA:
SECOND PART TO BE MEASURED: PIN
The following example is related to the gap measurement between a pin and its seat.
