Chapter 3 Engine Section 2 Engine Disassemble and Re-assemble
3—6
Re-assemble the engine
The re-assembly of the engine can be carried out in the
reverse order of removal.
Assemble the engine mounting bolts and nuts as shown
below.
Tighten the engine mounting nut to the specified torque.
As in Fig. 3.2.25
Tighten the rocker shaft nut to the specified torque. As in
Fig. 3.2.21
Rocker shaft nut：72N.m（7.2Kg,m）
Fig.3.2.21
Note：
The engine mounting nut is self-locking and cannot be reused after being removed.
Fig.3.2.25
