DRIVE SHAFT
03-13–1
03-13
03-13 DRIVE SHAFT
DRIVE SHAFT OUTLINE . . . . . . . . . . . . 03-13–1
DRIVE SHAFT STRUCTURAL VIEW . . . 03-13–2
FRONT DRIVE SHAFT STRUCTURE. . . 03-13–3
JOINT SHAFT OUTLINE . . . . . . . . . . . . . 03-13–3
Construction . . . . . . . . . . . . . . . . . . . . . 03-13–3
REAR DRIVE SHAFT STRUCTURE . . . . 03-13–4
End of Toc
NG: DRIVE SHAFT
DRIVE SHAFT OUTLINE
id031300151600
• A large size front drive shaft and joint shaft has been adopted, improving driveability and reducing noise/
vibration.
• A constant velocity joint system has been adopted for the rear drive shaft, improving driveability and reducing
noise/vibration.
End Of Sie
