CONVENTIONAL BRAKE SYSTEM
04-11–6
FRONT BRAKE (DISC) CONSTRUCTION
id041100100400
• A 17-inch brake, large diameter, ventilated disc
type front brakes with a 320 mm {12.6 in}
diameter and a 28 mm {1.1 in} thickness have
been adopted, improving braking force and fade
resistance.
End Of Sie
NG: REAR BRAKE (DISC)
REAR BRAKE (DISC) CONSTRUCTION
id041100100300
• A 17-inch brake, large diameter, ventilated disc
type rear brakes with a 325 mm {12.8 in}
diameter and 18 mm {0.71 in} thickness have
been adopted, improving braking force and fade
resistance.
• In addition, the disc plate also serves as the
parking drum.
End Of Sie
ac9uun00000289
ac9uun00000290
