EMISSION SYSTEM [MZI-3.5]
01-16–4
AWD
End Of Sie
NG: EXHAUST PURIFICATION SYSTEM
EXHAUST PURIFICATION SYSTEM OUTLINE [MZI-3.5]
id0116d1100400
Feature
• The EGI system (fuel injection control, ignition control) burns fuel supplied to the engine at the theoretical air/
fuel ratio for improved purification efficiency of the catalytic converter system.
End Of Sie
NG: CATALYTIC CONVERTER SYSTEM
CATALYTIC CONVERTER SYSTEM OUTLINE [MZI-3.5]
id0116d1101400
Feature
• Purifies contaminants in the exhaust gas by utilizing a chemical reaction in a three way catalytic converter.
End Of Sie
FUEL FILLER CAP
QUICK RELEASE CONNECTOR
FUEL SHUT-OFF VALVE
ROLLOVER VALVE
QUICK RELEASE CONNECTOR
QUICK
RELEASE
CONNECTOR
CV SOLENOID
VALVE
AIR FILTER
AIR FILTER
CHARCOAL CANISTER
CHARCOAL CANISTER
ac9uun00000024
