DYNAMIC STABILITY CONTROL/ROLL STABILITY CONTROL
04-18–8
Operation
During normal braking
• During normal braking, the solenoid valves are not energized and all of them are off. When the brake pedal is
depressed, brake fluid pressure is transmitted from the master cylinder, through the traction switch and inlet
solenoid valves, and then to the caliper piston.
Solenoid valve operation table
Traction control solenoid
valve
Stability control solenoid
valve
Inlet solenoid valve Outlet solenoid valve
Pump
motor,
pump
LF—RR RF—LR LF—RR RF—LR LF RF LR RR LF RF LR RR
OFF (open) OFF (closed) OFF (open) OFF (closed) Stopped
