POWER STEERING OUTLINE
id061400100100
• With the adoption of an engine speed sensing power steering mechanism, handling stability has been
improved.
• With the adoption, for all vehicles, of a steering column with a tilt/telescope mechanism, operability has been
improved.
• With the adoption of a steering shaft with an energy absorbing mechanism, safety has been improved.
End Of Sie
POWER STEERING STRUCTURAL VIEW
id061400100200
End Of Sie
NG: STEERING GEAR AND LINKAGE
FLUID RESERVOIR
POWER STEERING
OIL PUNP
STEERING COLUMN
AND SHAFT
STEERING WHEEL
STEERING GEAR
COOLING PIPE
ac9uun00000261
