Mazda CX-9 2007 - Dsc;Rsc Structural View

DYNAMIC STABILITY CONTROL/ROLL STABILITY CONTROL
04-18–3
04-18
DSC/RSC STRUCTURAL VIEW
id041800817700
End Of Sie
BRAKE
BRAKE
2WD
AWD
BRAKE SYSTEM
WARNING LIGHT
ABS WARNING
LIGHT
TCS OFF LIGHT
FRONT ABS WHEEL-
SPEED SENSOR
REAR ABS WHEEL-
SPEED SENSOR
REAR ABS WHEEL-
SPEED SENSOR
STEERING ANGLE
SENSOR
TCS OFF
SWITCH
COMBINED
SENSOR
DSC/RSC HU/CM
(BUILT INTO BRAKE
FLUID PRESSURE
SENSOR)
DSC INDICATOR
LIGHT
INSTRUMENT CLUSTER
ac9uun00000515
3423-1U-06H(04-18).fm 3 ページ ２００６年１１月２７日 月曜日 午前９時４４分
