COOLING SYSTEM [MZI-3.5]
01-12–5
01-12
WATER PUMP CONSTRUCTION/OPERATION [MZI-3.5]
id0112d1100400
Construction
• The water pump with the impeller built into the cylinder block has been adopted for size reduction.
• The water pump body is made of aluminum alloy and the impeller is made of plastic.
• The water pump is not serviceable and must be replaced as a single unit if it has a malfunction.
Operation
• The water pump is driven by the timing chain.
End Of Sie
NG: COOLING FAN
EXTERNAL VIEW
IMPELLER
GASKET
ac9uun00000474
