ON-BOARD DIAGNOSTIC [MZI-3.5]
01-02–4
Meaning of fuel system loop status
• The following information is displayed on the tester.
— Feedback operating: HO2S being used for feedback is normal.
— Feedback stops: ECT is lower than the determined feedback zone.
— Feedback stops: Open loop due to driving condition.
— Feedback stops: Open loop due to detected system fault.
Malfunction indicator lamp —
Distance travelled while MIL is activated km miles
Misfire detection monitor complete —
Misfire detection monitor enabled —
Misfire detection monitor evaluated —
Misfire detection monitor supported —
Front HO2S (RH) V
Rear HO2S (RH) V
Front HO2S (LH) V
Rear HO2S (LH) V
HO2S heater monitor complete —
HO2S heater monitor enabled —
HO2S heater monitor evaluated —
HO2S heater monitor supported —
HO2S monitor complete —
HO2S monitor enabled —
HO2S monitor evaluated —
HO2S monitor supported —
OBD requirement according to vehicle design —
Engine speed rpm
Run time s
Short term fuel trim (RH) %
Short term fuel trim (LH) %
Front short term fuel trim (RH) %
Front short term fuel trim (LH) %
Spark advance requested °
Throttle actuator control signal %
Absolute throttle position %
TP (sensor No.2) %
Relative throttle position %
Control module voltage V
Vehicle speed km/h mph
Number of warm-ups since DTCs cleared —
Full names Condition/unit
