AUTOMATIC TRANSAXLE [AW6A-EL, AW6AX-EL]
05-17–22
ELECTRONIC CONTROL SYSTEM CONSTRUCTION [AW6A-EL, AW6AX-EL]
id051723100100
End Of Sie
PCM
MAF/IAT SENSOR
CKP SENSOR
APP SENSOR
TFT SENSOR
TCC CONTROL
SOLENOID
SHIFT SOLENOID A, B
LINE PRESSURE
CONTROL SOLENOID
SHIFT CONTROL SOLENOID
COMPONENT
INPUT/TURBINE
SPEED SENSOR
VSS
· SHIFT SOLENOID C
· SHIFT SOLENOID D
· SHIFT SOLENOID E
· SHIFT SOLENOID F
TCM
SELECTOR LEVER COMPONENT
· M RANGE SWITCH
· UP SWITCH
· DOWN SWITCH
GEAR POSITION
INDICATOR LIGHT
AT WARNING
LIGHT
SELECTOR INDICATOR
LIGHT
CHT SENSOR
ac9uun00000406
