> Devices with LTE (4G) module - AT&T* - Type: MDH 862 AT&T, MDH 866 AT&T; from hardware version:
HW 03
Target region North America (Public safety, AT&T, FirstNet, T-Mobile, Canada)
HSxPA 1900 PCS (B2), AWS (B4), 850 (B5) MHz; Downlink max. 42 Mbps
LTE 700 Lower (B12), 700 PS (B14), AWS (B4), 1900 PCS (B2), 850 (B5), 700 Upper (B13),
AWS-3 (B66), 600 (B71) MHz; Downlink max. 150 Mbps, Uplink max. 50 Mbps
RF parameters
Output power - typical values for max output level
•
2G:
LB: 33 dBm; HB: 30 dBm
•
3G/TD-SCDMA: 24dBm
•
4G (FDD & TDD): 23dBm @1RB
Sensitivity - typical sensitivity levels
•
-108 dBm @ 2G
•
-113.5 dBm @ 3G
•
-103 dBm @ 4G FDD (BW=5 MHz)
Antenna connector
2 pieces SMA socket
TAC 35034498; 35432809; 35604311
FCC Contains FCC ID: RI7LE910CxNF
> Devices with LTE (4G) module - AT&T* - Type: MDH 862 AT&T, MDH 866 AT&T; hardware version: HW 02
Target region North America
GSM/GPRS/EDGE 850, 1900 MHz; max. 236 kbps
HSxPA 1900 (B2), 850 (B5) MHz; downlink max. 21 Mbps, uplink max. 5,76 Mbps
LTE 1900 (B2), AWS 1700 (B4), 850 (B5), 700 (B17) MHz; downl. max. 100 Mbps, upl. max. 50 Mbps
Transmission
output power
Class 4 (2 W, 33 dBm) @ GSM 850 / 900; Class 1 (1 W, 30 dBm) @ GSM 1800 / 1900
Class E2 (0.5 W, 27 dBm) @ EDGE 850 / 900; Class E2 (0.4 W, 26 dBm) @ EDGE 1800 /1900
Class 3 (0.25 W, 24 dBm) @ UMTS; Class 3 (0.2 W, 23 dBm) @ LTE
FCC FCC ID: R17LE910NA
NOTICE
*The device types MDH 862 AT&T and MDH 866 AT&T are not CE marked and must not be operated or
commissioned in the European Economic Area (EEA)!
