LED light codes
Designation LED-Status Description
off
Device power source is switched off or device is not connected to power
source/power pack.
Pwr (Power)
green
on Power source is connected to terminal block and switched on.
flashing
After the system has been checked and started (duration approx. 25 sec),
the LED flashes for the duration of the starting up process (approx. 90 sec).
Rdy (Ready)
green
on The device is ready for operation.
The Con LED signals the connection status to the Internet and portalserver.
off No connection to Internet or portal.
flashing (3Hz) Internet or VPN connection being established.
flashing (1,5Hz) Connection to portal server has been established.
Con (Connect)
orange
on Connection to the Internet has been established.
Light codes of the LED Usr directly after the start of SIMPLY.connect *-capable devices:
flashes briefly
at intervals
(500 msec on -
1500 msec off)
SIMPLY.connect is available but not activated.
This means: The SIMPLY.connect * function is supported by the device.
As long as the function is not activated by pressing the Function button, the
device remains in "normal mode" and no further action takes place.
If you do not want to use the Simply.connect * function, simply ignore this
display.
Usr (User)
orange
on SIMPLY.connect * is activated.
SIMPLY.connect * is active after the function button has been pressed.
The device tries to establish a connection to the SIMPLY.connect * server.
Light codes of the LED Usr during operation:
flashing (3Hz) Firmware on USB stick ready to be updated.
flashing (1,5Hz) Portal configuration on USB stick ready to be transferred.
Usr (User)
orange
on Firmware or configuration is being copied to the device.
orange flashing Network data transfer active
green on Transfer rate = 100 MBit/sWAN LED
green off Transfer rate = 10 MBit/s
orange flashing Network data transfer active
green on Transfer rate = 100 MBit/sLAN LED 1 – 3
green off Transfer rate = 10 MBit/s
* SIMPLY.connect is a web application that supports you when creating a device (industrial router mbNET) in the
Remote Service Portal mbCONNECT24.
You can find more information about SIMPLY.connect on our website at: https://simplyconnect.mbconnectline.com/
Page 16 von 131 | Version: 2.2.1 - EN | Mar 28
th
, 2022 |
