MB Connect Line mbNET.mini User Manual

View of bottom of device
- 0 V DC connection
+ Power source connection 10 - 30 V DC
FE Functional earth
1* I/O 1
2* I/O 2
* I/O 1 and I/O 2 can be configured independently of each other as digital input or digital output.
View of device from left Device dimensions - mm
Antenna connection
SIM-card slot
| Page 17 of 131
