102
Program Information
This eld displays operator and endoscope information as well as the normal progress of the disinfection
program. The expected end time, on the left, of each window is xed. Time remaining on the right, is
measured from the start of the cycle. This counter normally decreases as a cycle progresses, but may
increase or become xed if an error occurs. The progression of the steps, below the timers, is illustrated
with blue time bars. The real time is measured from the start of each step or phase.
Expert Information
This eld is visible and active to operators and system administrators with valid passwords. It provides
extra information for maintenance and troubleshooting.
Cycle and Program Errors
Operator messages and errors appear in the Reports eld and communicate cycle progress. An audible
alarm also sounds to communicate certain information.
A code number and short description of the report or error is shown, along with the elapsed time at which
it is generated. The most recent message is at the top of the eld. The meaning of each screen color is
shown in the table below:
Table 1 Screen Color and Program Status
Screen Color Program Status
1 Gray Program in Standby
2 Orange Standby, with lid open or a warning is present
3 Blue Cycle in progress
4 Red Error or cycle failed, endoscope not disinfected
5 Green Cycle Completed Successfully, endoscope disinfected
