Parameter Address
Default Min Max Unit Logic Diagram
“Logical”
communication
interface 2
COMM2: Function group COMM2
056 057
0: Without
[spacer]
Cancelling function group COMM2 or including it in the configuration. If the
function group is cancelled from the configuration, then all associated settings
and signals are hidden, with the exception of this setting.
[spacer]
COMM2: General enable USER
103 170
0: No Fig. 3-14, (p. 3-19)
[spacer]
Disabling or enabling communication interface 2.
[spacer]
COMM2: Line idle state
103 165
1: Light on / high Fig. 3-14, (p. 3-19)
[spacer]
Setting for the line idle state indication.
[spacer]
COMM2: Baud rate
103 071
19.2: 19.2 kBaud Baud Fig. 3-14, (p. 3-19)
[spacer]
Baud rate of the communication interface.
[spacer]
COMM2: Parity bit
103 171
2: Even Fig. 3-14, (p. 3-19)
[spacer]
Set the same parity that is set at the interface of the control system connected
to the P631.
[spacer]
COMM2: Dead time monitoring
103 176
1: Yes Fig. 3-14, (p. 3-19)
[spacer]
The P631 monitors telegram transmission to make sure that no excessive pause
occurs within a telegram. This monitoring function can be disabled if it is not
required.
Note: This setting is only necessary for modem transmission.
[spacer]
COMM2: Mon. time polling
103 202
25 3 254 s Fig. 3-14, (p. 3-19)
[spacer]
The time between two polling calls from the communication master must be less
than the time set here.
[spacer]
COMM2: Positive ackn. fault
103 203
0: No
[spacer]
It is possible to set whether or not faults can be acknowledged positively after
transmission (and consequently deleted from the fault overview at the
COMM2/PC interface).
7 Settings
