Parameter Address
Default Min Max Unit Logic Diagram
Binary input
INP: Filter
010 220
0 0 20 Fig. 3-22, (p. 3-37)
[spacer]
Input filter which is activated when either the mode Active "high", filt. or Active
"low", filt. has been selected for INP: Oper. mode U xxx. In order to
suppress transient interference peaks at the logic signal inputs it is suggested to
set this parameter to 6 [steps].
[spacer]
INP: Fct. assignm. U 701
152 109
061 000: MAIN: Without function
[spacer]
INP: Fct. assignm. U 702
152 112
061 000: MAIN: Without function
[spacer]
INP: Fct. assignm. U 703
152 115
061 000: MAIN: Without function
[spacer]
INP: Fct. assignm. U 704
152 118
061 000: MAIN: Without function
[spacer]
INP: Fct. assignm. U 705
152 121
061 000: MAIN: Without function
[spacer]
INP: Fct. assignm. U 706
152 124
061 000: MAIN: Without function
[spacer]
INP: Fct. assignm. U 901
152 145
061 000: MAIN: Without function
[spacer]
INP: Fct. assignm. U 902
152 148
061 000: MAIN: Without function
[spacer]
INP: Fct. assignm. U 903
152 151
061 000: MAIN: Without function
[spacer]
INP: Fct. assignm. U 904
152 154
061 000: MAIN: Without function
[spacer]
Assignment of functions to binary signal inputs.
[spacer]
INP: Oper. mode U 701
152 110
1: Active "high"
[spacer]
INP: Oper. mode U 702
152 113
1: Active "high"
[spacer]
INP: Oper. mode U 703
152 116
1: Active "high"
[spacer]
INP: Oper. mode U 704
152 119
1: Active "high"
[spacer]
INP: Oper. mode U 705
152 122
1: Active "high"
P631
7 Settings
7-52 P631/EN M/R-11-C // P631-310-650
