Micom P631 - Page 356

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MEASI: IDC,lin 9
037 167
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 10
037 169
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 11
037 171
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 12
037 173
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 13
037 175
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 14
037 177
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 15
037 179
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 16
037 181
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 17
037 183
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 18
037 185
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 19
037 187
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC,lin 20
037 189
1.200 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
Setting for the linearized current that will correspond to an input current that
has been set accordingly.
[spacer]
MEASI: Scaled val. IDC,lin1
037 192
0 -32768 32767 Fig. 3-27, (p. 3-42)
[spacer]
Setting for the scaled value of IDC,lin1.
[spacer]
MEASI: Scaled val.IDC,lin20
037 193
1200 -32768 32767 Fig. 3-27, (p. 3-42)
[spacer]
Setting for the scaled value of IDC,lin20.
