Micom P631 - Page 357

Parameter Address
Default Min Max Unit Logic Diagram
Binary and analog
output
OUTP: Fct. assignm. K 701
150 145
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 702
150 148
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 703
150 151
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 704
150 154
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 705
150 157
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 706
150 160
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 901
150 193
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 902
150 196
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 903
150 199
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 904
150 202
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 905
150 205
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 906
150 208
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 907
150 211
060 000: MAIN: Without function
[spacer]
OUTP: Fct. assignm. K 908
150 214
060 000: MAIN: Without function
[spacer]
Assignment of functions to output relays.
[spacer]
OUTP: Oper. mode K 701
150 146
1: ES updating
[spacer]
OUTP: Oper. mode K 702
150 149
1: ES updating
[spacer]
OUTP: Oper. mode K 703
150 152
1: ES updating
[spacer]
OUTP: Oper. mode K 704
150 155
1: ES updating
