Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LIMIT: T>>
014 101
200 -20 200 °C Fig. 3-137, (p. 3-169)
[spacer]
Setting for the operate value of temperature monitoring T>>.
[spacer]
LIMIT: tT>
014 103
Blocked 0 1000 s Fig. 3-137, (p. 3-169)
[spacer]
Setting for the operate delay of temperature monitoring T>.
[spacer]
LIMIT: tT>>
014 104
Blocked 0 1000 s Fig. 3-137, (p. 3-169)
[spacer]
Setting for the operate delay of temperature monitoring T>>.
[spacer]
LIMIT: T<
014 105
-20 -20 200 °C Fig. 3-137, (p. 3-169)
[spacer]
Setting for the operate value of temperature monitoring T<.
[spacer]
LIMIT: T<<
014 106
-20 -20 200 °C Fig. 3-137, (p. 3-169)
[spacer]
Setting for the operate value of temperature monitoring T<<.
[spacer]
LIMIT: tT<
014 107
Blocked 0 1000 s Fig. 3-137, (p. 3-169)
[spacer]
Setting for the operate delay of temperature monitoring T<.
[spacer]
LIMIT: tT<<
014 108
Blocked 0 1000 s Fig. 3-137, (p. 3-169)
[spacer]
Setting for the operate delay of temperature monitoring T<<.
