Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LOGIC: Op. mode t output 32
031 025
0: Without timer stage
[spacer]
These settings define the operating modes for the output timer stages.
[spacer]
LOGIC: Time t1 output 1
030 002
0.00 0.00 600.00 s Fig. 3-141, (p. 3-174)
[spacer]
LOGIC: Time t1 output 2
030 006
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 3
030 010
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 4
030 014
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 5
030 018
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 6
030 022
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 7
030 026
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 8
030 030
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 9
030 034
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 10
030 038
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 11
030 042
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 12
030 046
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 13
030 050
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 14
030 054
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 15
030 058
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 16
030 062
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 17
030 066
0.00 0.00 600.00 s
P631
7 Settings
7-94 P631/EN M/R-11-C // P631-310-650
