Micom P631 - Page 395

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LOGIC: Time t1 output 18
030 070
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 19
030 074
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 20
030 078
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 21
030 082
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 22
030 086
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 23
030 090
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 24
030 094
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 25
030 098
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 26
031 002
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 27
031 006
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 28
031 010
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 29
031 014
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 30
031 018
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 31
031 022
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t1 output 32
031 026
0.00 0.00 600.00 s
[spacer]
Settings of timer stage t1 for the respective outputs.
[spacer]
LOGIC: Time t2 output 1
030 003
0.00 0.00 600.00 s Fig. 3-141, (p. 3-174)
[spacer]
LOGIC: Time t2 output 2
030 007
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output 3
030 011
0.00 0.00 600.00 s
